| Description Of Goods: | MAΦ135/Φ350×350 Continuous Two Stand Tandem Cold Rolling Mill With Mechanical Pressdown Device By PLC Control System | Work Rollers (mm): | Φ135 |
|---|---|---|---|
| Roller Length (mm): | 250-350 | Rolling Force (Tons): | 120 |
| Input Thickness (mm): | ≤2.7 | Finished Thickness (mm): | ≥0.15 |
| Voltage: | 380V 50Hz 3phases Or Order By The User | Color: | As Our Standard Or Order By User |
| High Light: | PLC Control System Cold Rolling Mill,350mm Continuous Cold Rolling Mill,Two Stand Tandem Cold Rolling Mill |
||
MAΦ135/Φ350×350 Continuous Two Stand Tandem Cold Rolling Mill With Mechanical Pressdown Device By PLC Control System
Hydraulic AGC System
Functions: AGC (hydraulic control of press-down seam), AFC (constant rolling force control), pre-control of thickness gauge, monitoring, etc
Precision:
Stable rolling: 0.3mm ±4.5μm; 0.5-0.8mm ±7μm
Speed-up and speed-down rolling: 2%h≤±10μm
1. Description of goods:
MAΦ135/Φ350×350 continuous two stand tandem cold rolling mill with mechanical pressdown device by PLC control system
2. Advantages:
1. The second type of cold rolling mill controls rolling speed and its tension.
2. The stable rolling is ensured.
3. This machinery great guarantee the safety.
3. Techncial paramter:
| Type | Φ70/Φ210×250 | Φ135/Φ350×350 | Φ140/Φ450×450 | Φ175/Φ500×550 |
| Work rollers (mm) | Φ70 | Φ135 | Φ140 | Φ175 |
| Roller length (mm) | 250 | 250-350 | 450 | 500 |
| Rolling force (Tons) | 80 | 120 | 280 | 280 |
| Input thickness (mm) | 1.5 | ≤2.7 | ≤3 | ≤4 |
| Finished thickness (mm) | 0.08 | ≥0.15 | ≥0.3 | 0.3 |
| Width(mm) | 30-200 | ≤250 | 360 | 400 |
| Rolling speed (m/min) | 180 | 180 | 180 | 210 |
| Main motor (KW) | 22 | 55 | 75 | 90 |
| Press-down motor (KW) | 2.2 | 4 | 6 | 7.5 |
| Press-down speed (mm/s) | 0.06 | 0.08 | 0.08 | 0.08 |
| Speed reducer | JZQ650 | JZQ850 | JZQ450 | JZQ1000 |
| Weight (Tons) | 8.5 | 19 | 22 | 24 |
