Product Details:
|
| Raw Material: | Cold Hot Rolled Pre Slit Strip Coils Of Weld Able Grade With Max. 0.2% Carbon | Round Tube Outside Diameter: | Min 22, Max 114mm |
|---|---|---|---|
| Square Hollow Section: | Min25x 25, Max 90 X 90 Mm | Rectangular Hollow Section: | Min 25 X40, Max 80x 120 Mm |
| Tube Thickness: | Min 1.2, Max 4.5 Mm | Forming Line Speed: | Max 60 M/min (Square And Rectangular Hollow Shapes Are Produced At Lower Speeds Depending On Side To Wall Thickness Ratio) |
| Color: | As Our Standard Or Order By User | Voltage: | 380V 50Hz 3phases Or Order By The User |
| High Light: | 114mm High Frequency Welded Pipe Mill,60m/min High Frequency Welded Pipe Mill,90x90mm square tube mill |
||
1. Description of goods:
MA-Φ114 making high quality square and rectangular pipes wall thickness of 0.5~2.0 High Frequency Welded Pipe Mill
2. Specification complete line:
Finished product: Round Tubes, Square and Rectangular Hollow Sections
Round Tube Outside Diameter: Min 22, Max 114mm
Square Hollow Section: Min25x 25, Max 90 x 90 mm
Rectangular Hollow Section: Min 25 x40, Max 80x 120 mm
Tube Thickness: Min 1.2, Max 4.5 mm
Forming Line Speed: Max 60m/min (Square and Rectangular Hollow Shapes are produced at lower speeds depending on side to wall thickness ratio)
Tube Cut Length: Min 4 Max 12 meter
Length Accuracy: ± 3mm
| NO | Descriptions | Technical parameter | Remark |
| 1 | Round Tube Outside Diameter | Min 22, Max 114mm | |
| 2 | Square Hollow Section | Min25x 25, Max 90 x 90 mm | |
| 3 | Forming Line Speed | Max 60m/min | |
| 4 | Tube Cut Length | Min 4 Max 12 meter | |
| 5 | Length Accuracy | ± 3mm |
3. Main features:
1. We can make and design all kinds of special machine according to customer's requests.
2. This is a very perfect and durable equipment. We have more than 10 years experiences.
3. This kind of machine has the best quality and the best price. It has accurate measurement and easy operating.
4. We can design and manufacture the special type machine according to the customers' requirement and we could provide technical guiding, production, installation, debugging and maintenance service to all customers.
5. Our product has been exported to many regions and won high reputation because of the high quality and reasonable price.
4. The whole line layout drawing as reference:
