Product Details:
|
| Raw Material: | Cold Hot Rolled Pre Slit Strip Coils Of Weld Able Grade With Max. 0.2% Carbon | Round Tube Outside Diameter: | Diameter: Min 114, Max 219mm |
|---|---|---|---|
| Square Hollow Section: | Min 90 X90, Max 170x170 Mm | Rectangular Hollow Section: | Min 80x 100, Max140x 200 Mm |
| Tube Thickness: | Min 2.2, Max 8.0 Mm | Forming Line Speed: | Max 45m/min (Square And Rectangular Hollow Shapes Are Produced At Lower Speeds Depending On Side To Wall Thickness Ratio) |
| Color: | As Our Standard Or Order By User | Voltage: | 380V 50Hz 3phases Or Order By The User |
| High Light: | ISO High Frequency Welded Pipe Mill,High Frequency Welded Pipe Mill 0.5-2.0mm,219mm tube mill for carbon steel |
||
1. Description of goods:
MA-Φ219 High Frequency Welded Pipe Mill for making high quality square and rectangular pipes wall thickness of 0.5~2.0
2. Specification complete line:
Material to be processed: carbon steel, cold hot rolled pre slit strip coils of weld able grade with max. 0.2% carbon
| No | Descriptions | Technical parameter | Remark |
| 1 | Round Tube Outside Diameter | Min 114, Max 219mm | |
| 2 | Square Hollow Section | Min 90 x90, Max 170x170 mm | |
| 3 | Rectangular Hollow Section | Min 80x 100, Max140x 200 mm | |
| 4 | Tube Thickness | Min 2.2, Max 8.0 mm | |
| 5 | Forming Line Speed | Max 45m/min (Square and Rectangular Hollow Shapes are produced at lower speeds depending on side to wall thickness ratio) | |
| 6 | Tube Cut Length | Min 4 Max 12 meter | |
| 7 | Length Accuracy | ± 3mm |
3. Main features:
1. We can make and design all kinds of special machine according to customer's requests.
2. This is a very perfect and durable equipment. We have more than 10 years experiences.
3. This kind of machine has the best quality and the best price. It has accurate measurement and easy operating.
4. We can design and manufacture the special type machine according to the customers' requirement and we could provide technical guiding, production, installation, debugging and maintenance service to all customers.
5. Our product has been exported to many regions and won high reputation because of the high quality and reasonable price.
4. The whole line layout drawing as reference:
