Product Details:
|
| Product Name: | Slitting Machine For Steel | Material Of Coils: | HRC, CRC, GI, PPGI, Q195, Q235, Q345 |
|---|---|---|---|
| Strip Thickness: | 0.3-3mm | Max. Strip Width: | 1600mm |
| Coil ID: | ≥Φ508mm | Coil OD: | Φ1800mm |
| Max. Coil Weight: | 20000Kgs | Slitter Motor: | 75KW DC Motor |
| High Light: | Q235 Steel Coil Slitting Machine,Q345 Steel Coil Slitting Machine,100m/min high speed slitter machine |
||
1. Product Description:
Steel Coil Slitting Line with stably speed or can be orderd by user for different size coils and different thickness
2. Technical Parameters:
3. Specifications:
| Model | Thickness | Coil Weight | Finished slit | Max Slitting speed | |
| MA-1 x 600 | 0.2-1mm | 100-600mm | Max 8T | Min. 20mm | 50m/min |
| MA-2 x 1300 | 0.3-2mm | 300-1300mm | Max 15T | Min. 25mm | 80m/min |
| MA-3 x 1600 | 0.3-3mm | 500-1600mm | Max 20T | Min 25mm | 100m/min |
| MA-4 x 1600 | 0.4-4mm | 500-1600mm | Max 30T | Min 30mm | 80m/min |
| Note: The data in the form just as reference according to general ranges, we always design and make each line according to each customer’s specific requirements, so each customer can buy his own well-content line from us. | |||||
