Product Details:
|
| Material Of Coils: | HRC, CRC, GI, PPGI, ST37, ST52..... | Voltage: | 380V 50Hz 3phases Or Order By The User |
|---|---|---|---|
| Quality Guarantee: | One Year After Shipping. | Machine Color: | It’s Order By The User Or By Our Standard |
| Packing: | Machine Will Be Fixed Inside Container By Steel Wire(Export Standard Sea Package) | After Service: | Avalible On Any Local China Working Time |
| Highlight: | 600mm steel coil slitting line,ST37 steel coil slitting line,0.2-1mm cr slitting machine |
||
1. Product Description:
Steel Coil Slitting Line with Stably Speed or can be orderd by user auto rotary shear machine
2. Technical data:
3. Specifications:
| Model | Thickness | Coil Weight | Finished slit | Max Slitting speed | |
| MA-1 x 600 | 0.2-1mm | 100-600mm | Max 8T | Min. 20mm | 50m/min |
| MA-2 x 1300 | 0.3-2mm | 300-1300mm | Max 15T | Min. 25mm | 80m/min |
| MA-3 x 1600 | 0.3-3mm | 500-1600mm | Max 20T | Min 25mm | 100m/min |
| MA-4 x 1600 | 0.4-4mm | 500-1600mm | Max 30T | Min 30mm | 80m/min |
| Note: The data in the form just as reference according to general ranges, we always design and make each line according to each customer’s specific requirements, so each customer can buy his own well-content line from us. | |||||
